設計 |
5-driver, 2-way bass-reflex includes powered drivers and passive radiators. |
|
分頻點 |
2nd-order electro-acoustic at 2.6 kHz |
|
響應頻率 On-Axis |
±3 dB from 120 Hz – 21 kHz |
|
響應頻率 30° Off-Axis |
±3 dB from 120 Hz – 15 kHz |
|
高音單體 |
One 25-mm (1 in) S-PAL™ dome, ferro-fluid damped/cooled |
|
中高音單體 |
Two 114-mm (4-1/2 in) anodized unibody cones, 37-mm (1-1/2 in) high-temperature aluminum voice coils, Nomex spike, Nitrile-Butadiene rubber surround, neodymium magnet, integrated moving magne/motor heat dissipation system, tempered steel heatfin basket. |
|
低音單體 |
Two 114-mm (4-1/2 in) anodized unibody cones, Nitrile-Butadience rubber surround, precision-tuned resonance system. |
|
低頻率擴展 |
75 Hz (DIN) |
|
靈敏度 Room / Anechoic |
92 dB / 89 dB |
|
阻抗 |
Compatible with 8 ohms |
|
合適的放大器功率範圍 |
15 – 130 watts |
|
最大輸入功率 |
70 watts
|
|
表面處理 |
Black gloss with brushed aluminum accents |
|
重量 |
3.0 kg
|
|
尺寸 HxWxD |
64.2cm × 16.2cm × 4.7cm
|
|
|
產品規格如有變更，以實際產品為主，恕不另行通知。 |
