Frequency Response
20–120 Hz ±3dB; Anechoic through LFE effects input
Impedance
RCA: 10,000 Ohms
XLR: 15,000 Ohms per phase
Speaker Level: 10,000 Ohms per phase (20,000 Ohms red to black) Compatible with 4, 6, or 8 Ohm rated amplifiers.Low Frequency Transducer
Two 10" (25.4cm) cast-basket, highexcursion, aluminum cone with extended throw driver assembly, sealed non-resonant asymmetrical chamber format
Amplifier
850 watts
(1,700 watts peak)Room Correction (Bass Section)
Perfect Bass Kit (PBK) Ready (Sold Separately)
Audio Controls
On, Auto (12V Trigger), Off
Low Pass Filter Frequency
30 - 80Hz
Inputs
RCA: Left, Right and LFE.
XLR: Left, Right and LFE.
Speaker Level: Left and Right banana jacks.
12V Trigger: 3.5mm
Mini USB (for PBK)
USB (for crossover & firmware updates)Power Draw
Typical: 125 Watts
Idle: 15 Watts
